Reinforced main arm & base with thickened structural design boosts overall rigidity by 20% for stable long-term operation.

High-load precision ensures ±0.05 mm repeatability even under heavy-duty working conditions.

Fast & precise motion delivers instantaneous linear speeds up to 3 m/s while maintaining ±0.05 mm positioning repeatability.

Equipped with 750W high-power servo motor, increasing load capacity by 20% for heavy-duty handling tasks.

Optimized low-inertia section design reduces vibration amplitude by 20% during operation, ensuring reliable continuous long-term running.

Compatible with standard injection molding machine signals and Euro-standard quick-connect ports; significantly reduces equipment installation time.

Detects the actual open and closed positions of the mold and automatically compensates for the robot’s travel, reducing alarms and manual adjustments caused by inaccurate mold positioning.

Supports multiple languages; the open-source operating system allows for quick and easy editing and modification of programs.

24/7 support, with user manuals and video tutorials available.

Yubao injection molding robots support Ethernet interfaces, enabling real-time remote monitoring and management through data acquisition.

Real-time tracking and analysis of production data, along with comprehensive monitoring of robotic arm operation throughout the entire process, enable efficient production management, timely troubleshooting, and unmanned intelligent production without the need for on-site supervision.

The high-capacity I/O board supports up to 12 suction cup channels, 12 gripper channels, 12 pneumatic shearing channels, conveyor line synchronization control channels, and auxiliary interfaces such as mold release agent spraying channels simultaneously.

This enables the robot to connect multiple suction cups, grippers, and auxiliary devices at the same time, allowing it to complete complex grasping, handling, and loading tasks in a single operation.

Designed for two critical industrial application scenarios:

• High-load operating conditions with stable positioning
• Non-standard insertion and embedding operations

Maintains accurate positioning under heavy loads to avoid position deviation; delivers precise alignment for non-standard tasks to ensure operation accuracy and consistency.

Dedicated programming commands for non-standard and customized automation needs, ideal for complex production scenarios:

• Custom motion path planning and editing
• Specialized gripping logic definition and setting
• Flexible adaptation to unique customer production processes

High customization allows the BaoTa series to flexibly meet various specialized and personalized industrial production requirements.

Dedicated programming commands for non-standard and customized automation needs, ideal for complex production scenarios:

• Pneumatic Scissors: Pneumatic scissors can be installed for gate cutting.
• Finished Product Inspection: Sensors can be installed on the conveyor belt. Place finished products on the conveyor belt to prevent collisions between products.
• A/C-Axis Servo Drive: Both ends of the robotic arm’s rotation mechanism can be driven by AC servo motors, supporting multiple angles and various movements; the A-axis allows free rotation within 180 degrees, and the C-axis allows free rotation within 360 degrees.
• Mold Position Detection: After the mold opens to its end position, the center plate position is detected in real time to prevent the sprue arm from colliding with the center plate.
• Automatic Timed Lubrication Function: Can be equipped with either a manual centralized lubrication system or an automatic timed lubrication system. For automatic lubrication, the system will automatically lubricate when the robot’s operating time reaches a preset value.
• Quick End-Effector Replacement: Enables rapid disconnection of the end-effector from the robot. Operation is simple: replacement can be performed immediately with the push of a button, saving time during end-effector changes.
• Additional suction and gripping devices: The standard configuration includes 2 suction cup channels, 2 gripper channels; the system supports up to 12 suction cup channels, 12 gripper channels.
